Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A
Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A
Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A
Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A
Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A
Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A
Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A
Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

DRAPER

Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A

SKU: DRA34886
£707.75 ex. VAT £849.30 inc. VAT

Was £859.50 Ex.Vat

In stock
Usually ships within 24 hours

Got questions?

Feel free to get in touch

3-phase, heavy duty transformer with 4 x 16A and 2 x 32A 110V outlets. Hard-wearing steel enclosure. Elevated underside for improved access. Double wound with safety earth screen. Supplied without plug or cable. Intermittent rating 10000VA. Continuous rating 7000VA. Duty cycle 5 mins on / 15 mins off. Ingress protection rating: IP44. BSEN 61558-1 compliant. Dimensions: 775 x 515 x 800mm. Weight 80kg.

Contents:
1 x Defender ZE210027 110V 10kVA 3-Phase Transformer, 16A/32A
4 x 16A Socket
2 x 32A socket

Specification:
Input voltage: 400-415V - 3P
Output voltage: 110V
Apparent Power (kVA): 10KVA
Intermittent duty rated output: 10000VA (10KVA)
Continuous duty rated output: 7000VA(7.0KVA
IP Rating: IP44
Rated Power Factor: 0.93 cos
Socket Outlet configuration: 4X16A Socket + 2X32A socket
Dimensions: 775 x 500 x 545mm
Weight: 80.5kg

Dimensions: 775 x 500 x 545mm
